GENERAL
♦ Off-road Caravan
♦ 14ft Couples single axle caravan
♦ Sleeps 2

DIMENSIONS
♦ Open – TBC
♦ Closed (Travel Size) – TBC
♦ Annex Size – TBC

WEIGHTS & RATINGS
♦ Tare weight Approx. 2400kg
♦ Towball weight Approx. 200kg
♦ ATM Rating 3000kg
♦ Payload Approx. 600kg

CHASSIS
♦ 12″ Electric drum brakes
♦ Cruisemaster DO35 hitch
♦ Hot dip galvanised chassis with heavy-duty black protective finish drawbar
♦ CASP 1500kg high-lift scissor jack
♦ ARK XO750 jockey wheel
♦ X-TRACK trailing arm suspension with dual TOUGH TRAX HD shock absorbers
♦ Aluminium water tank guards with heavy-duty black protective finish
♦ 16″ Alloy wheels with 265/75 Goodride M/T tyres

BODY CONSTRUCTION
♦ Black aluminium checker plate panel external trimming
♦ One-piece thermoplastic composite honeycomb floor
♦ Welded aluminium wall and roof frames
♦ One-piece fibreglass external roof skin
♦ Aluminium composite exterior wall panels and fibreglass composite internal wall panels

EXTERIOR
♦ 48V Dometic Freshjet 7 Series 2500W air conditioner
♦ Electric cassette awning
♦ Full annex, enclosed roof, walls, floor and draft skirt
♦ Collapsible wall-mounted clothes line
♦ Tuson asymmetric electronic stability control
♦ Double manual pull out entry step
♦ Hot/cold external shower
♦ 1040mm L x 530mm W x 480mm H (fridge slide)
♦ 2 x 9kg gas cylinder holders
♦ Truma AquaGo Comfort Plus instant water heater (gas-operated)
♦ 1 x 20L jerry can holder
♦ Rear-mounted service ladder
♦ 12V LED lighting with yellow bug light function (external)
♦ 12V LED underbody strip lighting (underbody)
♦ Wireless rear view camera with monitor
♦ 2 x ladder-mounted MAXTRAX MKII recovery tracks
♦ Slide-out external kitchen with Thetford 3-burner gas cooktop and sink with hot and cold water supply.
♦ Multi-compartment front storage box & rear storage bar
♦ Through-wall cable port
♦ 12-pin flat trailer plug
♦ 2 x 80L fresh water & 1 x 80L grey water

INTERIOR
♦ Internal ensuite with Dometic cassette toilet & separate shower
♦ 1 x Queen size island bed
♦ 2100mm L x 1580mm W x 220mm H (mattress size)
♦ Eberspächer D2L Airtronic AS3 2.2kW diesel air heater
♦ Outback slate cabinetry, oak benchtops, stone wash grey premium leatherette upholstery, and matte black fixtures
♦ Dometic 2-zone induction cooktop
♦ NCE 29L 4 in 1 convection microwave (air fryer, grill, oven & microwave)
♦ 12V LED mood lighting
♦ Dometic NRX130 130L compressor fridge
♦ Straight lounge
♦ Stereo head unit with internal & external speakers
♦ NCE 24″ Google ready smart TV
♦ Inline water filter
♦ Caframo Sirocco II

POWER MANAGEMENT
♦ 700W of rooftop solar
♦ 3 x portable solar power inlet ports (portable solar not supplied)**
♦ Projecta Intelli-Grid 48V Power Management System
♦ Projecta 48V 210Ah (10.8kWh) chassis mounted lithium battery bank (2 x 48V 105Ah Batteries) – equivalent to 840Ah capacity at 12V
♦ Projecta INVCHR4-48V Inverter/charger
↳ 4000W 48V Inverter integrated into Projecta INVCHR4-48V
↳ 70A AC charger integrated into Projecta INVCHR4-48V – equivalent to 280A at 12V
↳ 30A DC-DC charger integrated into Projecta INVCHR4-48V
↳ 30A MPPT solar controller integrated into Projecta INVCHR4-48V – equivalent to 120A at 12V
♦ Projecta IGCMD18 18 channel 12V master output module
♦ Projecta 10″ colour touch screen with smart device connectivity
♦ Projecta levelling sensor
♦ Projecta tyre pressure monitoring system

Please Note: **Combined rooftop and expandable solar inputs can deliver up to 30A charging at 48V (120A equivalent at 12V)

INTERNAL POWER OUTLETS
♦ 12V accessory sockets
♦ USB charging ports
♦ 240V GPOs
♦ F-type TV outlet
♦ Wireless charging pads

EXTERNAL POWER OUTLETS
♦ 12V accessory socket
♦ USB charging ports
♦ 240 GPOs
♦ F-type TV outlet
♦ F-type TV inlet
♦ Anderson plug

MAJOR FEATURES
♦ 48V 210Ah Projecta Lithium Battery Power (840Ah at 12V)
♦ 700W of rooftop solar
♦ 4000W Projecta Inverter Charger
♦ 48V Dometic Air-conditioning
♦ NCE Convection microwave with airfryer function
♦ 130L Internal Fridge
♦ Separate Shower & Toilet Ensuite
♦ External Slide Out Kitchen
